  Heavy duty cylinder bed sewing machines

dot  Heavy duty thick thread flat sewing machine

dot  FIBC bulk bags making machines

dot  Heavy duty zigzag sail making machines

dot  Long arm heavy duty sewing machines

dot  Heavy post bed thick thread sewing machine

dot  Heavy duty automatic pattern sewing machine

dot  Cutting machines for slings/ropes and leather

dot  Spare parts and special sewing accessories

dot  Hot air welding machine & ultrasonic welder

dot  Custom sewing units and sewing automation

dot  Special sewing machines for shoes factory


double needle thick thread sewing machine

204-370-DP Heavy duty post bed triple feed double needle lockstitch sewing machine with 2 large Barrel shuttle hook for ultra strong thread decorative seams on leather

Features: Max. metric thread size 7, V415, T-400, 1300dx3 or Amann Serabraid Thread 1400 T60 braided thread can be use without any difficulty; The post bed design gives you greater access and control when sewing decorative (top stitching) & functional stitching on shaped or 3d items, which would normally be difficult or impossible to sew on a standard flat bed machine; Its heavy duty combined triple feeding action by way of: bottom feed, needle feed and walking foot top feed, guarantees effective handling of medium to heavy weight materials, leather and fabrics etc; Pneumatic climbing device for excellent stitch formation when sewing over thick spots or overlapping seams; Up to 14 mm long stitches for decorative topstitching seams ; Thread puller is available for even thread tension.

Applications: for functional and ornamental stitching luxurious leather sofas, fabric sofas, armchair, couch lounge, chair, car seat covers, upholstered furniture, shoes, saddles, leather crafts, automotive upholstery, marine upholstery, aerospace upholstery, leather bags and other high-end leather goods.

  Ready More


programmable decorative stitching machine

204-370-PRO Post bed sewing machine twin needle, triple feed, crochet Barrel, suitable for twin needle seams and decorative seams on very thick materials and leather with braided thread

Features: Thick thread upholstery sewing machine takes a giant step forward with the 7204-370PRO and its revolutionary rotating needle bar. The 7204-370PRO combines all the benefits of the 204-370 heavy duty triple transport machine with large Barrel shuttle hook. Max. metric thread size 7, V415, T-400, 1300dx3 or 1.0 - 1.2 mm braided thread can be use without any difficulty; Using the machine in twin-needle mode offers the possibility to use 16 standard decorative stitch patterns and 16 user designed patterns but the machine can also be used in single needle mode simply by removing 1 needle and then another 16 stitch patterns will come available; Up to 14 mm long stitches for decorative topstitching seams.

Applications: Special sewing machine for sewing decorative stitches on leather sofas, fabric sofas, armchair, couch lounge, chair, car seat covers, upholstered furniture, shoes, saddles, leather crafts, automotive upholstery, marine upholstery, aerospace upholstery, leather bags and other high-end leather goods.

  Ready More


thick thread sewing machine

723698(R/L) Heavy duty, post bed, compound feed and walking foot lockstitch upholstery sewing machine with extra large vertical axis hook
724698 Heavy duty, post bed, twin needle, compound feed and walking foot lockstitch upholstery sewing machine with two extra large vertical axis hooks (for braided thread up to 1.0 mm)
724698MD Heavy duty, thick thread, two needle, post bed, triple feed, ornamental stitch sewing machine for decorative seams on leather

Features: For sewing extra heavy weight materials such as fabric, plastic, leather, webbing, fiberglass, Kevlar, rubber; Compound feed and walking foot mechanism assures even feeding of materials; High needle penetration power guarantee easy sewing thick spots or cross seams(over transversal seams), without skipped stitch, loose bottom thread, shorten stitch length, bobbin thread Knots and Tangles; The sewing foot stroke up to 9 mm allows the safe climbing over differently high material plies; Pneumatic climbing device for excellent stitch formation when sewing over thick spots or overlapping seams; Up to 12 mm long stitches for decorative topstitching seams; Thread puller is available for even thread tension; Front tape guide is available for double stitch with under tape strengthening, saddle stitch and top stitch; Piping cord insert is available; This machine is an ideal replacement of Durkopp Adler 868-290321 and Durkopp Adler H868-290361.

Applications: assemble and topstitching leather sofas and furniture, car seat covers, automotive upholstery/car interiors, marine upholstery, shoe uppers, handbags, jeans, tarpaulins, covers, awnings, tents, umbrellas, luggage, travelware accessories, sports and camping equipment, wearing apparel, outdoor clothing, footwear, foundation garments and orthopedic appliances.

Click here for video


Specifications

Max. Speed

Presser lift

Stitch length

Post height

Needle system

Working area

723698

1200 rpm

23mm

10mm

185mm

DYx 3 #24-26

508*153mm

724698

1200 rpm

23mm

10mm

185mm

DYx 3 #24-26

508*153mm

724698MD

600 rpm

23mm

10mm

185mm

DYx 3 #24-26

508*153mm


post bed upholstery sewing machine
768-373 Triple feed post bed upholstery sewing machine for single needle topstitching
768-273 Triple feed post bed upholstery sewing machine for double needle topstitching

Features: For use in many sections of the heavy duty industry including the manufacture & topstitching of high-end leather sofas and furniture, car upholstery & interiors, leather goods, filters, technical textiles, plastic and laminated products etc.; The post bed design gives you greater access and control when sewing decorative (top stitching) & functional stitching on shaped or 3d items; Its heavy duty triple feeding action by way of: bottom feed, needle feed and walking foot top feed, guarantees effective handling of medium/heavy weight leather and fabrics; Safety clutch prevents damage to the hooks, bevel gears and other important parts; Front tape guide is available for double stitch with under tape strengthening, saddle stitch and top stitch; Optional pneumatic seam centre guide available combined with compensating topstitching presser foot.

Applications: leather sofas, fabric sofas, car interiors in automotive upholstery industry, upholstered furniture, jeans, general upholstery panels/shapes, leather goods, canvas/plastic, handbags, shoe uppers, (leather or synthetic leather), sports apparatus, medical apparatus, soft cushions etc.

Click here for video


Specifications

Max. Speed

Presser lift

Stitch length

Post height

Needle system

Working area

768-373

2000 rpm

16mm

7mm

178mm

DP x 17 #22-24

254*178mm

768-273

2000 rpm

16mm

7mm

178mm

DP x 17 #22-24

254*178mm


post bed shoes sewing machine
71579 High quality single needle post-bed sewing machine for shoe manufacture
72579 High quality twin needle post-bed sewing machine for shoe manufacture

Features: Modern post-bed high-speed seamers for shoe manufacture; The versatile post bed design allows you to stitch hollow, tubular and shaped items; Its Positively Driven Roller Presser provide a powerful feed for the materials which are hard to feed and climbing stitches over thick section, and ensures constant stitch length and smooth material feed; The roller foot allows for detailed edge sewing; The large vertical hook with 60% more thread capacity reduces the number of bobbin changes; The machines can be equipped with thread trimmer, automatic presser foot, backtacking mechanism and side cutter (options).

Applications: for ornamental stitches and assembly seams in the manufacturing of shoe uppers, leather bags, leather crafts, handbag, leather sofas, upholstery/car interiors.

Specifications

Max. Speed

Presser lift

Stitch length

Post height

Needle system

Working area

71579

2500 rpm

14mm

6mm

178mm

DP x 17 #22-24

254*178mm

72579

2500 rpm

14mm

6mm

178mm

DP x 17 #22-24

254*178mm


shoes sewing machine


78810 Single needle post bed sewing machine with driven top & bottom roller feed system

78820 Twin needle post bed sewing machine with driven top & bottom roller feed system

Features: This machine is designed for stitching light to medium heavy items such as: leathers, boot tops, shoes, straps, upholstery and other difficult to feed material including: vinyl, polyethylene plastics, oil cloth, canvas, coated and laminated fabrics etc; The versatile post bed design allows you to stitch hollow, tubular and shaped items which can not normally be done on standard flat bed sewing machines; The driven top & bottom roller feed system makes it easier to do fancy or detailed stitching where many changes in stitch direction are required; With strong servo motor (Powerful + Quiet + Accurate Speed Control, different from so call "Energy Saving Servo Motor"or "Power Saving Servo Motor" in the market.

Applications: shoe uppers (leather or synthetic leather), boot tops, leather upholstery, car upholstery, general upholstery panels/shapes, leather goods, canvas/plastic, handbags, sports apparatus, office furniture, soft cushions etc.

Specifications

Max. Speed

Presser lift

Stitch length

Needle gauge

Working area

78810

2500 rpm

14mm

7mm

DP*5 #11-20

254*178mm

78820

2500 rpm

14mm

4mm

DP*5 #11-20

254*178mm
