204-370 Extra heavy duty flat bed triple feed lockstitch
sewing machine with large Barrel shuttle hook for very
thick sewing threads and heavy materials



Adler 204-370 sewing machine

Your advantages:

1. Due to the extremely sturdy design and powerful & effective triple feed system guarantees a trouble-free and displacement-free material feed when processing most different fabric thicknesses, result in excellent stitch pattern and constant stitch length;

2. The 204 class heavy duty sewing machine with large Barrel shuttle has been specially designed for processing the extreme thick thread and heavy weight materials;

3. The large bobbin capacity offers high efficiency in sewing production when using extra thick thread up to metric size 7* (=V415, T-400, 1300dx3);

4. The presser foot has an extra high lift and can go up to 20mm, allowing for a large range of extra heavy weight material or bulky items to be used;

5. Excellent climbing properties guarantee easy sewing thick spots or overlapping cross seams, without skipped stitch. The great advantage of 204-370 becomes especially apparent when processing topstitching seams in leather goods or in the furniture upholstery;

6. Up to 14 mm long stitches for assembly and decorative seams;

7. Using low speed, high torque extra powerful servo motor (Click here for detail) that allowing you to slow down your sewing machine and sew stitch by stitch (eliminates the need for a now obsolete, "Speed Reducer");

Low speed leather sewing machine servo motor

8. Standard supplied with needle positioner that automatically stops the needle in the Down and Up position, good for improving efficiency;

9. Standard supplied with pneumatic presser foot lift and pneumatic reverse stitch, your productivity may increase substantially;

10. A full array of special sewing attachments are available for high productivity and perfect seam quality.


Typical Application and Subclass:

204-370BF Upholstery sewing machine for thick thread decorative seams: leather sofas and armchairs, office chair, car upholstery and marine upholstery

204-370CS Webbing sewing machine for technical textiles: webbing lifting slings, cargo lashing straps, safety harness, military belts, backpacks, parachutes,sails, tents, tarps, filters, industrial safety products and tire covers

204-370BP Buffing wheel sewing machine: for spiral sewn buffing wheels and polishing wheels made in cotton, sisal, flannel and Denim


Specifications:

Max. Sewing Speed:

800 rpm

Hook Type:

HAD-204 Barrel Shuttle Hook

Presser Foot Lift:

20mm

Needle bar stroke:

56 mm

Needle System:

794 needle, #160-#280

Max. Thread size

8/3 (=V415, T-400) or 1.4mm Braided yarn

Stitch Length:

0-14mm

Bobbin size:

Outside Dia. 24mm, Height 30.5mm

Take up stroke:

96 mm

Presser foot alternating:

10mm

Working space:

320mm (length) x185mm( High)

Recommended motor:

Minimum 0.75 kW

Packing size:

770x620x520MM, 85KGS

Tariff code (HS code):

8452290000



Need to expand your production and maximize profits? Contact us at info@automatic-sewing.com
