7245 Heavy duty upholstery sewing machine
with compound feed, bigger hook and binding
attachment synchronized with feed movement



Pfaff 1245 upholstery sewing machine
Pfaff 1245
2 times large rotary hook


Mauser Spezial MA1245Synchronized binding attachment

Your advantages:

1.Compound feed: Lockstitch has compound feed and higher needle bar stroke (36mm). This solution enables to technical sewing. Presser foot lifting height is 16mm. It also improves technical sewing;

2. Bigger hook: Lockstitch has bigger hook, which is perfect for technical sewing. Bigger hook enables to use bigger bobbin (60% bigger than in standard size). Hook has own automatic lubrication system;

3. Top feed stroke: Possibility of regulation of top feed stroke guarantees high climbing capacity, ideal quality of stitch regardless of kind of sewn material, and easily sewing over cross seams;

4. Binding attachment synchronized with feed movement: Lockstitch with binding attachment enables to sewing and sewing in piping at the same time;

5. Hook protection against thread jamming: Efficient hook protection against thread jamming due to standard built-in overload coupling (M);

Applications:

This one needle lockstitch is perfect for medium and heavy sewing, compound feed manages with leather and car and furniture upholstery. Machine is ideal for sewing sofa covers, car seat covers, leather bags, shoes, jeans, suitcase, webbing, container bags, hand bags, curtains, tents, awnings, lorry curtain sidings, camping goods and general canvas work etc.


Specifications:

Max. Sewing Speed:

2000 rpm

Hook Type:

Large vertical rotary hook

Presser Foot Lift:

14mm

Needle bar stroke:

36 mm

Needle System:

Needle system 134-35 (#90-#150)

Max. Thread size

20/3

Stitch Length:

0-8mm

Bobbin size:

Outside Dia. 26mm, Height 11.2mm

Amount of alternating foot:

standard 7 mm

Balance wheel Dia.:

80 mm

Working space:

257mm (length) x110mm( High)

Recommended motor:

Minimum 0.55 kW

Packing size:

630x280x600MM, 44KGS

Tariff code (HS code):

8452290000
